Travis Steel, located in Canberra, Australia, is a reliable manufacturer and supplier of top-notch wear-resistant steel products, including the high-performance NICRODUR 500 Sheet and Plates. Known for their quality and precision, Travis Steel caters to various industries such as mining, construction, and heavy machinery, providing solutions that can handle extreme wear and impact. With a strong dedication to excellence and customer satisfaction, the company guarantees that every product adheres to strict Australian and international standards. Their NICRODUR 500 plates are celebrated for their exceptional strength, durability, and reliability, making Travis Steel the go-to partner for businesses that need robust and long-lasting steel solutions in tough environments.
NICRODUR 500 Sheet and Plates are specially alloyed, quenched, and tempered wear-resistant steels with a nominal hardness of 500 HBW. The typical chemical makeup includes Carbon (0.25–0.30%), Manganese (up to 1.50%), Chromium (0.80–1.50%), along with Nickel, Molybdenum, and trace amounts of Silicon. These elements work together to provide outstanding hardness, toughness, and high impact resistance. The mechanical properties boast a tensile strength of around 1,600 MPa and a yield strength exceeding 1,200 MPa. Despite their high hardness, the plates maintain good formability and weldability, making them suitable for demanding applications in abrasive environments.
Item: NICRODUR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness [mm] | C max | Si max | Mn max | S max | P max | Cr max | Ni max | Mo max | B max | CEV max | |
| 8 – 25 | 0,28 | 1,0 | 1,5 | 0,002 | 0,012 | 1,0 | 0,5 | 0,5 | 0,005 | 0,61 | |
| (20) – 40 | 0,32 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,005 | 0,71 | |
| (40) – 60 | 0,34 | 1,0 | 1,5 | 0,002 | 0,012 | 1,2 | 0,7 | 0,5 | 0,005 | 0,76 | |
| (60) – 80 | 0,40 | 1,0 | 1,5 | 0,002 | 0,012 | 1,5 | 1,0 | 0,5 | 0,005 | 0,81 |
| Yield strength(minimal), Re [MPa] | Tensile strength, Rm [MPa] | Elongation (minimal), A5 [%] | |
| NICRODUR 500 | 1500 | 1800 | 9 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
