Travis Steel, located in Canberra, Australia, stands out as a top manufacturer and supplier of **Carbon Steel EN 10224 Pipes**. These pipes are crafted with a focus on strength, durability, and reliability, making them perfect for various industrial and structural applications. With a reputation for adhering to international standards, Travis Steel ensures that each pipe is produced with exceptional dimensional accuracy and mechanical performance, allowing for consistent operation even in challenging conditions. EN 10224 Pipes are widely utilized across the water, chemical, and oil & gas sectors, thanks to their impressive corrosion resistance, weldability, and toughness. Committed to quality and customer satisfaction, Travis Steel has earned its place as a trusted provider of high-performance piping solutions both in Australia and around the globe.
The composition of Carbon Steel EN 10224 Pipes includes carbon, manganese, phosphorus, sulfur, and trace amounts of silicon, which together create an ideal mix of strength, ductility, and toughness. These pipes boast a tensile strength that ranges from 360 to 510 MPa, with a minimum yield strength of 235 MPa. They are known for their excellent weldability, corrosion resistance, and mechanical stability. Thanks to their chemical makeup and mechanical properties, these pipes promise long-lasting durability, structural integrity, and dependable performance in medium-pressure piping and various industrial applications.
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.17 | max 0.35 | max 0.80 | 0.04 | 0.04 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10224 Pipe products in Canberra, Australia. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that provide outstanding performance in various industrial applications. Rely on Jaxon Steel for all your Carbon Steel EN 10224 Pipe requirements.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10224 Pipes find extensive use in water supply systems, chemical processing facilities, oil and gas pipelines, and structural applications due to their robust strength and resistance to corrosion. They are particularly well-suited for transporting fluids, supporting industrial machinery, and providing structural support where precision and durability are crucial. Additionally, these pipes are commonly used in fabrication projects, construction endeavors, and engineering applications that demand mechanical reliability and precise dimensions. With their compliance to EN standards, along with strong mechanical properties and meticulous manufacturing, Carbon Steel EN 10224 Pipes are the go-to choice for industries looking for long-lasting, high-performance piping solutions.
Travis Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Canberra, Australia.
