Travis Steel, located in Canberra, Australia, stands out as a top manufacturer and supplier of SA 516 GR.65N NACE HIC Plates, delivering high-quality steel solutions tailored for critical industrial and pressure vessel applications. These plates are meticulously designed to comply with rigorous international standards, including NACE MR0103, which ensures they resist sulfide stress cracking and hydrogen-induced cracking. This commitment to safety and reliability makes them perfect for sour environments. Renowned for their toughness, durability, and performance, Travis Steel’s SA 516 GR.65N NACE HIC Plates are the go-to choice for clients who need materials that can maintain their structural integrity and provide long-lasting service in demanding sectors like oil, gas, petrochemical, and chemical industries.
Manufactured from premium carbon steel with carefully controlled chemical compositions, SA 516 GR.65N NACE HIC Plates boast exceptional mechanical properties. They offer impressive tensile strength, yield strength, and impact toughness, even in low temperatures, while also resisting sulfide stress cracking and hydrogen-induced cracking. These plates are not only highly weldable and formable but can also be fabricated into pressure vessels, storage tanks, and structural components without sacrificing performance or safety. Their robust mechanical properties make them ideal for harsh operational and sour service environments where reliability is paramount.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Canberra, Australia. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
These plates find extensive use in the oil and gas, petrochemical, and chemical industries for crafting pressure vessels, boilers, storage tanks, pipelines, and structural components that face sour and corrosive conditions. Their unique blend of high strength, toughness, and resistance to HIC and sulfide stress cracking guarantees safety, reliability, and a prolonged service life. Engineers and designers consistently choose SA 516 GR.65N NACE HIC Plates for critical applications that demand structural integrity, durability, and operational safety in challenging and sour service environments.
Travis Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Canberra, Australia.
