Travis Steel, located in Canberra, Australia, is a reputable manufacturer and supplier of top-notch Carbon Steel API X70 5L PSL 1 Pipes, designed specifically for tough pipeline and industrial applications. The company is recognized for its precision, durability, and adherence to international standards, ensuring that their products consistently perform well and offer long-lasting reliability. With state-of-the-art production facilities and strict quality control measures, Travis Steel delivers pipes that are not only dimensionally accurate but also structurally sound and finished to high standards. API X70 5L PSL 1 pipes are prized for their remarkable strength, toughness, and resistance to corrosion, making them perfect for projects involving oil, gas, and water pipelines.
These Carbon Steel API X70 5L PSL 1 Pipes generally contain between 0.06–0.12% carbon, 1.00–1.60% manganese, along with trace elements of silicon, sulfur, and phosphorus. This specific composition grants them high tensile strength, good toughness, and excellent weldability, ensuring they perform reliably in various environmental conditions. The pipes maintain consistent mechanical properties, impact resistance, and dimensional stability. Additionally, controlled rolling and heat treatment processes boost their strength and ductility, making API X70 5L PSL 1 pipes ideal for high-pressure and long-distance pipeline applications.
| X70 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Grade of material | X70 / L485 (N, M, Q, R) |
| Standard | ISO 3183 L485/ API 5L X70 |
| API 5L X70 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr X70 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X70 Steel SAW | 16″ – 100″ NB |
| API 5L X70 PSL1 Pipe end | Flanged Ends, Buttweld, Square Cut, Coupling, Pub Joints, Thread Cutting, Cut Grooves, Deburring, Squared Ends, Beveled End (BE), Vibrator Grinding, Socket, Grooved, Screwed, Chamfering, Plain end (PE), Threaded Ends (Male & Female) |
| Manufacturing process | Welded, Seamless, Longitudinally Submerged Arc Welded (LSAW), Electro Fusion Seam Welded (EFSW), Submerged Arc Welded (SAW), Cold Drawn Seamless (CDS), Horizontal Submerged Arc Welded (HSAW), Extrusion, Hot Finish Seamless (HFS), Electric Resistance Welded (ERW) |
| API 5L X70 Wall Thickness | SCH-XXS, SCH160, SCH-XS, SCH40, SCH-STD, SCH80 |
| Equivalent Standards | KS, AISI, ISO, BS, SS, EN, JIS, AWWA, CSA, GOST, SAE, GB, ANSI, NFA, ASTM, API, DIN, IS, UNI |
| PSL Level | |
| X70 Carbon Steel Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| Mass fraction, based upon heat and product analysis a | |||||||
| Carbon Steel PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 485(70 300) | 570(82 700) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| NB | DN | OD (inches) | API 5L X 70 Carbon Steel Seamless Pipe Schedule | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCH 5 | SCH 10 | SCH 20 | SCH 30 | SCH 40 | SCH 60 | SCH 80 | SCH 100 | SCH 120 | SCH 160 | |||
| 3/4″ | 20 | 1.05 | 0.065 | 0.11 | x | 0.095 | 0.113 | x | x | 0.17 | x | 0.219 |
| 1″ | 25 | 1.315 | 0.065 | 0.11 | x | 0.114 | 0.133 | x | x | 0.2 | x | 0.25 |
| 1.1/2″ | 40 | 1.9 | 0.065 | 0.11 | x | 0.125 | 0.145 | x | x | 0.225 | x | 0.281 |
| 2″ | 50 | 2.375 | 0.065 | 0.12 | x | x | 0.154 | x | x | 0.25 | x | 0.344 |
| 2.1/2″ | 65 | 2.875 | 0.083 | 0.12 | x | x | 0.203 | x | x | 0.3 | x | 0.375 |
| 3″ | 80 | 3.5 | 0.083 | 0.12 | x | x | 0.216 | x | x | 0.35 | x | 0.438 |
| 4″ | 100 | 4.5 | 0.083 | 0.12 | x | x | 0.237 | x | x | 0.437 | x | 0.531 |
| 5″ | 125 | 5.563 | 0.109 | 0.12 | x | x | 0.258 | x | x | 0.5 | x | 0.625 |
| 6″ | 150 | 6.625 | 0.109 | 0.13 | x | x | 0.28 | x | x | 0.562 | x | 0.719 |
| 8″ | 200 | 8.625 | 0.109 | 0.15 | 0.25 | 0.277 | 0.322 | 0.406 | 0.593 | 0.718 | 0.812 | 0.906 |
| 10″ | 250 | 10.75 | 0.134 | 0.17 | 0.25 | 0.307 | 0.365 | 0.5 | 0.718 | 0.843 | 1.0 | 1.125 |
| 12″ | 300 | 12.75 | 0.165 | 0.18 | 0.25 | 0.33 | 0.406 | 0.5 | 0.843 | 1.0 | 1.125 | 1.312 |
Travis Steel is a leading supplier of high-quality Carbon Steel API X70 5L PSL 1 Pipes products in Canberra, Australia. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X70 5L PSL 1 Pipes are extensively utilized in oil and gas, water transmission, and energy infrastructure projects that demand high strength, toughness, and corrosion resistance. They are commonly found in both onshore and offshore pipelines, including those for crude oil, natural gas, and water distribution systems. Thanks to their superior mechanical properties and weldability, these pipes are well-suited for extreme environmental conditions and high-pressure scenarios. API X70 5L PSL 1 pipes are also favored in industrial and construction projects where durability, safety, and long-term service are crucial, providing reliable and efficient solutions for essential pipeline networks.
Travis Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Canberra, Australia.
