Travis Steel, located in Canberra, Australia, stands out as a top-notch manufacturer and supplier of premium Carbon Steel A192 Tubing, specifically designed for high-pressure and industrial applications. The company has built a reputation for precision, durability, and strict adherence to international standards, ensuring that their products consistently perform well and offer long-lasting reliability. With state-of-the-art manufacturing facilities and a strong focus on quality control, Travis Steel crafts tubing that is not only dimensionally accurate but also structurally sound and finished to meet exact specifications. A192 Tubing is highly sought after for its remarkable strength, resistance to corrosion, and ability to handle high-pressure situations, making it perfect for boilers, heat exchangers, and industrial piping systems.
Typically, Carbon Steel A192 Tubing contains 0.15–0.25% carbon, 0.30–0.60% manganese, along with trace amounts of silicon, sulfur, and phosphorus. This specific blend gives it high tensile strength, good ductility, and excellent weldability, ensuring it performs reliably under high-pressure and elevated-temperature conditions. The tubing maintains consistent mechanical properties, impact resistance, and dimensional stability. Through controlled manufacturing and heat treatment processes, its toughness, durability, and corrosion resistance are enhanced, making A192 Tubing a great choice for demanding industrial and mechanical applications where performance and safety are paramount.
| Craft | Cold rolled and Cold drawn |
| Standards | ASTM, ASME and API |
| Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | Seamless / ERW / Welded / Fabricated |
| Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Form | Round, Hydraulic Etc |
| Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter ASTM A192 Pipe |
| Size | 1/2” NB to 36” NB |
|
C, % |
Mn, % |
Si, % |
P, % |
S, % |
|
0.06-0.18 |
0.27-0.63 |
0.25 max |
0.035 max |
0.035 max |
|
Tensile Strength , MPa |
Yield Strength , MPa |
Elongation, % |
Hardness, HB, WT≥5.1mm |
Hardness, HRB, WT＜5.1mm |
|
325 min |
180 min |
35 min |
137 max |
77 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A192 Tubing in Canberra, Australia. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A192 Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
You’ll find Carbon Steel A192 Tubing widely used in high-pressure boilers, heat exchangers, power generation plants, and industrial piping systems that require strength, durability, and resistance to corrosion. It’s a common choice in chemical processing facilities, petrochemical industries, and oil and gas operations. Thanks to its excellent mechanical properties, weldability, and ability to handle pressure, this tubing is well-suited for extreme operational and environmental conditions. A192 Tubing is also favored in industrial and mechanical projects where long-term service, safety, and structural integrity are crucial, providing dependable and robust solutions.
Travis Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Canberra, Australia.
