Travis Steel, a top-notch manufacturer and supplier located in Canberra, Australia, specializes in high-quality ABS AH36 Shipbuilding Steel Sheets and Plates. These products are celebrated for their remarkable strength, toughness, and resistance to corrosion. Designed to comply with strict international marine standards, these plates are perfect for the rigorous demands of shipbuilding and offshore structural projects. Travis Steel prides itself on precision manufacturing, consistent quality, and a fantastic surface finish, making its ABS AH36 offerings a reliable choice for tough marine environments. The maritime industry trusts these steel plates for their durability, weldability, and long-lasting performance in both structural and hull construction.
ABS AH36 Shipbuilding Steel Sheets and Plates are mainly made up of carbon, manganese, silicon, phosphorus, and sulfur, with a few trace elements like nickel and chromium to boost corrosion resistance. They boast a minimum yield strength of 355 MPa and a tensile strength ranging from 490 to 620 MPa, ensuring they can handle heavy loads with ease. These plates are known for their exceptional toughness, weldability, and impact resistance, performing reliably even in low temperatures and challenging sea conditions, making them ideal for high-strength marine and offshore structures.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: AH 36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| C | Si | Mn | P | S | Cr | Mo | Ni | Cu | Cb | V |
| 0.18 | 0.10/0.50 | 0.90/1.60 | 0.035 | 0.035 | 0.20 | 0.08 | 0.40 | 0.35 | 0.02/0.05 | 0.05/0.10 |
| Grade | Re | Rm | Elongation | |
| A50mm | A200mm | |||
| MPan | MPa | % | % | |
| AH36 | 355 | 490/620 | 22 | 19 |
| DNV | GL | LR | BV | CCS | NK | KR | RINA |
| NV A36 | GL A36 | LR A36 | BV AH36 | CCS A36 | KA36 | RA 36 | RINA AH36 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Travis Steel is one of the most prominent manufacturers and suppliers of superior quality ABS AH36 Shipbuilding Steel Sheet and Plates in Canberra, Australia. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| Grade A | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
You’ll find ABS AH36 Shipbuilding Steel Sheets and Plates widely used in constructing ships, offshore platforms, and various marine engineering projects. They’re perfect for building hulls, decks, bulkheads, and superstructures that face the harshness of seawater and dynamic stresses. Beyond shipbuilding, these plates are also utilized in oil rigs, naval vessels, and floating structures where strength and corrosion resistance are paramount. Their outstanding mechanical performance and formability guarantee reliability, safety, and longevity in demanding marine and offshore settings.
